SCOPE OF LEARNING:
• Study of V-I Characteristics of Solar Cell
SALIENT FEATURES:
• Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
• Fuse for Short Circuit protection
• Instruction manual.
• Connections are brought out through 4mm Colored Sockets.
• Patch Cords 4mm.
• The trainer is housed in ABS Plastic cabinet.
• Size of the trainer set 12”x8”
ACCESSORIES:
• Trainer Unit
• Solar Cell Unit
• Light Source 100W Filament
• Wooden Optical Bench
OPTIONAL ACCESSORIES:
• Lux Meter
TECHNICAL SPECIFICATIONS:
Digital Meters:
• Volt meter 20V DC.
• Ammeter 200mA DC
• Digital Temperature Meter.
Power Supplies:
• Operated on Mains power 230V, 50Hz +10%
• DC Power Supply 0-+3V,100mA
Components are mounted on the panels are:
• Solar Cell Unit (Mounted on Stand)
• Light Source (100W Bulb) Lamp
• Load Control through Potentiometer.
• Temperature Probe For Solar Cell
