USB Digital Microscope (MT-MX Series)
Product Specification Sheet
USB Digital Microscope (MT-MX Series)
Model Number: MTDM-02
The USB Digital Microscope (MT-MX Series) is a compact and portable digital imaging solution designed for magnified inspection, image capture, video recording, and measurement applications. Manufactured by Micro Technologies, it offers USB connectivity, adjustable LED illumination, high-resolution image capture, and multiple magnification options, making it ideal for laboratories, educational institutions, electronics inspection, quality control, research, and industrial applications.
Product Specification
The USB Digital Microscope (MT-MX Series) is designed to deliver high-quality digital imaging for scientific observation, laboratory analysis, electronics inspection, educational demonstrations, industrial quality control, and research applications. Manufactured by Micro Technologies, this portable microscope combines optical magnification with digital imaging technology to provide real-time observation directly on a computer screen.
The microscope connects to a computer through a USB 2.0 interface, allowing users to capture high-resolution images and videos for documentation, analysis, reporting, and presentations. The built-in CMOS image sensor delivers sharp images with excellent color reproduction, while adjustable LED illumination provides clear viewing under varying lighting conditions.
The manual focus mechanism allows precise focusing from approximately 10 mm to 500 mm, making the microscope suitable for observing electronic components, biological specimens, textiles, jewelry, printed circuit boards, coins, stamps, insects, plants, educational samples, and industrial products.
Integrated LED lighting with adjustable brightness ensures uniform specimen illumination and improves image clarity even under low ambient light conditions. The lightweight and portable design makes the microscope convenient for both laboratory and field applications.
The microscope supports still image capture in JPEG and BMP formats and records videos in AVI format, making it suitable for documentation, teaching, laboratory records, inspection reports, and quality assurance procedures.
Available in multiple sensor resolutions and magnification ranges, the MT-MX Series provides flexible solutions for laboratories, educational institutions, industrial inspection departments, electronics manufacturing, forensic laboratories, and research organizations.
Manufactured by Micro Technologies, every USB Digital Microscope undergoes quality inspection for optical performance, image quality, electronic reliability, and long-term operational stability before delivery.
Features
- Compact portable USB digital microscope
- USB 2.0 computer connectivity
- High-quality CMOS image sensor
- Manual focus adjustment
- Focus range: 10 mm to 500 mm
- Adjustable LED illumination
- Brightness control wheel
- Real-time live viewing
- High-resolution image capture
- AVI video recording
- JPEG & BMP photo formats
- Plug-and-play operation
- Stable metal support stand
- Lightweight portable design
- Suitable for laboratory and industrial inspection
- Multiple sensor resolutions available
Benefits
- Real-time digital observation
- High-quality image documentation
- Easy computer connectivity
- Adjustable lighting for improved visibility
- Suitable for microscopic inspection
- Compact and portable
- Easy image and video recording
- Ideal for education and research
- Simple operation
- Reliable long-term performance
- Multiple magnification options
- Cost-effective digital microscopy solution
Product Specifications
| Specification | Details |
|---|---|
| Product Name | USB Digital Microscope |
| Model Series | MT-MX |
| Interface | USB 2.0 |
| Focus Type | Manual |
| Focus Range | 10 mm – 500 mm |
| Image Format | JPEG, BMP |
| Video Format | AVI |
| Frame Rate | Up to 30 fps (Under 600 Lux) |
| Illumination | 8 Adjustable LED Lights |
| Brightness Control | Manual Control Wheel |
| Power Supply | 5V DC via USB Port |
| Operating System | Windows Compatible (Depending on Software Version) |
| Applications | Laboratory, Education, Electronics Inspection, Quality Control, Research |
Available Models
| Model | Image Sensor | Resolution | Magnification |
|---|---|---|---|
| MT-MX01 | 1.3 MP CMOS | Up to 1600 × 1200 | 20X & 200X |
| MT-MX02 | 2 MP CMOS (Interpolated to 5 MP) | Up to 2560 × 2048 | 20X & 200X |
| MT-MX04 | 1.3 MP CMOS (Interpolated) | Up to 1600 × 1200 | 20X & 400X |
Optional Accessories
- Adjustable microscope stand
- Flexible arm stand
- Calibration ruler
- Measurement software
- Image analysis software
- Carrying case
- Additional LED illumination
- USB extension cable
- Protective lens cap
- Calibration certificate
SKU System
- MT-MX01
- MT-MX02
- MT-MX04
FAQs
What is the MT-MX USB Digital Microscope used for?
The MT-MX Series is used for laboratory observation, electronics inspection, PCB analysis, biological specimen viewing, quality control, educational demonstrations, jewelry inspection, forensic analysis, and industrial applications.
How does the microscope connect to a computer?
The microscope connects directly through a USB 2.0 interface, allowing live viewing, image capture, and video recording.
Can images and videos be saved?
Yes. Images can be saved in JPEG and BMP formats, while videos are recorded in AVI format.
Does the microscope include adjustable lighting?
Yes. The microscope features 8 built-in LED lights with adjustable brightness for improved specimen visibility.
What is the focusing range?
The manual focusing system operates between approximately 10 mm and 500 mm.
Which models are available?
The MT-MX Series includes MT-MX01, MT-MX02, and MT-MX04, offering different sensor resolutions and magnification options.
Where is the USB Digital Microscope commonly used?
It is widely used in laboratories, schools, colleges, universities, electronics manufacturing, PCB inspection, jewelry inspection, forensic science, research institutes, and industrial quality control departments.
Can the MT-MX Series be supplied in bulk?
Yes. Micro Technologies supplies the MT-MX Series for institutional procurement, OEM requirements, government tenders, distributors, exporters, educational projects, and industrial inspection applications.
Why Choose Our Products
- High-resolution digital imaging
- Reliable USB connectivity
- Adjustable LED illumination
- Multiple magnification options
- Compact portable design
- Easy image and video recording
- Suitable for laboratory and industrial applications
- OEM manufacturing support
- Competitive B2B pricing
- Strict quality inspection
- Reliable technical support
- Excellent after-sales service
Call to Action
Choose the USB Digital Microscope (MT-MX Series) from Micro Technologies for high-quality digital microscopy, precise inspection, and reliable image documentation. Contact us today for pricing, customized solutions, OEM manufacturing, government tenders, distributor inquiries, or a competitive quotation.
