Portable Vertical Autoclave (MT-183 Series)
Product Specification Sheet
Portable Vertical Autoclave (MT-183 Series)
Model Number: MTAC-04
The Portable Vertical Autoclave (MT-183 Series) is a reliable steam sterilization unit designed for laboratories, hospitals, clinics, pharmaceutical industries, and research institutions. Manufactured by Micro Technologies, the autoclave features a deep-drawn seamless aluminum chamber, mirror-finished body, heavy-duty lid locking system, and capacities ranging from 22 to 40 litres. Available in both electric and non-electric models, it provides safe, efficient, and dependable sterilization of laboratory instruments, glassware, culture media, dressings, and surgical equipment.
Product Specification
The Portable Vertical Autoclave (MT-183 Series) is a high-quality laboratory sterilization system developed to provide efficient steam sterilization using saturated steam under pressure. Manufactured by Micro Technologies, this portable autoclave is suitable for sterilizing laboratory equipment, microbiological media, surgical instruments, glassware, culture vessels, dressings, rubber items, and other heat-resistant materials.
The autoclave is manufactured with a deep-drawn seamless aluminum chamber, ensuring excellent durability, corrosion resistance, and uniform heat distribution. Models are also available with stainless steel construction, offering enhanced durability for demanding laboratory and medical applications.
The mirror-finished body provides an attractive appearance while simplifying cleaning and maintenance. The heavy-duty lid is secured with multiple locking knobs, ensuring a tight and leak-proof seal during sterilization. A pressure gauge and safety valve are incorporated for safe monitoring and pressure control throughout the sterilization cycle.
The MT-183 Series is powered by a 2 kW heating element operating on 220V AC, 50Hz, single-phase power, delivering rapid steam generation and efficient sterilization. Both electric and non-electric versions are available to meet different operational requirements.
Available in 22-litre, 26-litre, and 40-litre capacities, the autoclave offers flexibility for laboratories of different sizes. Its portable vertical design allows easy transportation and installation while occupying minimal bench space.
Manufactured by Micro Technologies, every Portable Vertical Autoclave undergoes stringent quality inspection to ensure reliable sterilization performance, operational safety, and long service life. The MT-183 Series is widely used in pharmaceutical industries, microbiology laboratories, hospitals, pathology laboratories, universities, research institutes, food testing laboratories, biotechnology laboratories, and industrial quality control facilities.
Features
- Portable vertical steam sterilizer
- Deep-drawn seamless aluminum chamber
- Stainless steel chamber option available
- Mirror-finished body
- Heavy-duty lid locking system
- Steam sterilization under pressure
- Built-in pressure gauge
- Safety valve protection
- Heavy-duty heating element
- 2 kW electric heater
- Electric and non-electric models available
- Compact vertical design
- Corrosion-resistant construction
- Easy operation and maintenance
- Long service life
Benefits
- Efficient steam sterilization
- Uniform heat distribution
- Reliable laboratory performance
- Leak-proof pressure sealing
- Fast heating and sterilization
- Compact and portable design
- Durable construction
- Low maintenance requirements
- Safe operation
- Suitable for continuous laboratory use
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Portable Vertical Autoclave (MT-183 Series) |
| Product Type | Portable Steam Sterilizer |
| Chamber Material | Deep-Drawn Seamless Aluminum / Stainless Steel (Optional) |
| Finish | Mirror Finish |
| Heating System | Electric Heater |
| Heater Rating | 2 kW |
| Power Supply | 220V AC, 50Hz, Single Phase |
| Operation | Electric / Non-Electric Models Available |
| Construction | Vertical Portable Design |
| Sterilization Method | Steam Under Pressure |
| Applications | Laboratory Sterilization, Medical Sterilization, Pharmaceutical Processing, Microbiology, Research Laboratories |
Available Models
| Model | Chamber Size | Capacity |
|---|---|---|
| MT-183(A) | 12" × 12" | 22 Litres |
| MT-183(B) | 12" × 15" | 26 Litres |
| MT-183(C) | 12" × 20" | 40 Litres |
Optional Accessories
- Stainless Steel Chamber
- Electric Heating System
- Non-Electric Heating Version
- Digital Temperature Controller
- Digital Pressure Indicator
- Spare Rubber Gasket
- Stainless Steel Basket
- Calibration Certificate
SKU System
- MT-183-A
- MT-183-B
- MT-183-C
FAQs
What is the MT-183 Portable Vertical Autoclave used for?
The MT-183 Series is used for steam sterilization of laboratory glassware, microbiological media, surgical instruments, dressings, rubber articles, and heat-resistant laboratory equipment.
What chamber capacities are available?
The MT-183 Series is available in 22 litres, 26 litres, and 40 litres.
What material is used for the chamber?
The standard model features a deep-drawn seamless aluminum chamber, with stainless steel construction available as an option.
What power supply is required?
The electric model operates on 220V AC, 50Hz, single-phase power with a 2 kW heating element.
Are electric and non-electric models available?
Yes. The MT-183 Series is available in both electric and non-electric configurations.
Which industries commonly use the MT-183 Series?
The Portable Vertical Autoclave is widely used in pharmaceutical industries, microbiology laboratories, hospitals, pathology laboratories, universities, biotechnology laboratories, research institutes, food testing laboratories, and industrial quality control departments.
Can the MT-183 Series be supplied in bulk?
Yes. Micro Technologies offers OEM manufacturing, institutional procurement, government tender supply, distributor support, export orders, and bulk industrial supply.
Why Choose Our Products
- Reliable steam sterilization performance
- Deep-drawn seamless chamber construction
- Heavy-duty safety locking system
- Electric and non-electric options
- Compact portable design
- Long operational life
- OEM and customized manufacturing
- Competitive pricing
- Bulk supply capability
- Strict quality inspection
- Professional technical support
- Reliable after-sales service
Call to Action
Looking for a reliable Portable Vertical Autoclave (MT-183 Series)? Micro Technologies manufactures and supplies premium portable steam sterilizers designed for pharmaceutical industries, microbiology laboratories, hospitals, universities, biotechnology laboratories, research institutes, food testing laboratories, and industrial quality control facilities. Contact us today for customized specifications, OEM manufacturing, government tenders, distributor inquiries, bulk orders, or a competitive quotation.
