Horizontal High Pressure Autoclave (MT-187 Series)
Product Specification Sheet
Horizontal High Pressure Autoclave (MT-187 Series)
Model Number: MTAC-07
The Horizontal High Pressure Autoclave (MT-187 Series) is a heavy-duty steam sterilization system designed for large-volume sterilization in pharmaceutical industries, hospitals, laboratories, biotechnology facilities, and research institutes. Manufactured by Micro Technologies, the autoclave features a triple-wall cylindrical stainless steel chamber, radial locking door, automatic pressure control, automatic low-water cut-off protection, and capacities ranging from 78 to 221 litres. It delivers efficient, safe, and uniform steam sterilization for laboratory equipment, surgical instruments, glassware, media, and industrial components.
Product Specification
The Horizontal High Pressure Autoclave (MT-187 Series) is an industrial-grade steam sterilizer engineered for continuous, high-capacity sterilization under controlled pressure and temperature conditions. Manufactured by Micro Technologies, this horizontal autoclave is designed to meet the demanding sterilization requirements of pharmaceutical production units, hospitals, research laboratories, biotechnology facilities, food testing laboratories, and industrial quality control departments.
The autoclave incorporates a cylindrical triple-wall pressure chamber manufactured from high-quality stainless steel, providing excellent thermal insulation, superior heat retention, and uniform steam distribution. The robust construction minimizes heat loss while ensuring efficient sterilization throughout the chamber.
The MT-187 Series features a heavy-duty stainless steel radial locking door, providing secure sealing under high-pressure operation. The radial locking mechanism distributes pressure evenly around the chamber opening, ensuring leak-proof operation and enhanced operator safety.
The autoclave is equipped with an automatic pressure control switch, allowing precise pressure regulation during sterilization. An integrated automatic low-water level cut-off device protects the heating system from damage by automatically disconnecting power when the water level falls below the safe operating limit.
Operating on 440V AC, 3-phase power supply, the MT-187 Series is designed for continuous industrial operation and delivers rapid steam generation for efficient sterilization of laboratory glassware, microbiological media, surgical instruments, culture vessels, dressings, rubber articles, pharmaceutical equipment, and other heat-resistant materials.
Available in capacities from 78 litres to 221 litres, the Horizontal High Pressure Autoclave provides excellent flexibility for medium to large-scale sterilization requirements. Its horizontal loading configuration allows convenient loading and unloading of bulky laboratory equipment and large sterilization batches.
Manufactured by Micro Technologies, every Horizontal High Pressure Autoclave undergoes rigorous quality inspection to ensure dependable sterilization performance, operational safety, and long service life. The MT-187 Series is widely used in pharmaceutical industries, hospitals, biotechnology laboratories, universities, research institutes, food testing laboratories, microbiology laboratories, and industrial manufacturing facilities.
Features
- Horizontal high-pressure steam sterilizer
- Triple-wall cylindrical chamber
- Stainless steel chamber construction
- Heavy-duty radial locking door
- Automatic pressure control switch
- Automatic low-water level cut-off
- Uniform steam distribution
- High-pressure sterilization
- Heavy-duty industrial construction
- Corrosion-resistant stainless steel body
- Large-capacity chamber
- Continuous-duty operation
- Easy loading and unloading
- Reliable safety protection
- Long operational life
Benefits
- Efficient large-volume sterilization
- Uniform temperature distribution
- Enhanced operator safety
- Reliable pressure control
- Automatic low-water protection
- Reduced heat loss
- High sterilization efficiency
- Heavy-duty industrial durability
- Low maintenance requirements
- Long service life
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Horizontal High Pressure Autoclave (MT-187 Series) |
| Product Type | Horizontal Steam Sterilizer |
| Chamber Design | Cylindrical Triple Wall |
| Chamber Material | Stainless Steel |
| Door Type | Radial Locking Stainless Steel Door |
| Pressure Control | Automatic Pressure Control Switch |
| Safety Protection | Automatic Low Water Level Cut-Off |
| Power Supply | 440V AC, 3 Phase |
| Sterilization Method | Steam Under Pressure |
| Construction | Heavy-Duty Industrial Design |
| Applications | Laboratory Sterilization, Medical Sterilization, Pharmaceutical Processing, Biotechnology, Microbiology, Research Laboratories |
Available Models
| Model | Chamber Size | Capacity |
|---|---|---|
| MT-187(A) | 16" × 24" | 78 Litres |
| MT-187(B) | 16" × 44" | 162 Litres |
| MT-187(C) | 20" × 36" | 165 Litres |
| MT-187(D) | 20" × 48" | 221 Litres |
Optional Accessories
- Digital Temperature Controller
- Digital Pressure Indicator
- Automatic Steam Exhaust System
- Automatic Water Filling System
- Stainless Steel Loading Basket
- Data Logger
- Calibration Certificate
- PLC-Based Control System
SKU System
- MT-187-A
- MT-187-B
- MT-187-C
- MT-187-D
FAQs
What is the MT-187 Horizontal High Pressure Autoclave used for?
The MT-187 Series is used for high-capacity steam sterilization of laboratory glassware, microbiological media, surgical instruments, pharmaceutical equipment, culture vessels, dressings, and other heat-resistant materials.
What type of chamber construction is provided?
The autoclave features a triple-wall cylindrical stainless steel chamber, providing superior insulation, uniform heating, and improved energy efficiency.
What safety features are included?
The MT-187 Series includes an automatic pressure control switch, automatic low-water level cut-off device, and a heavy-duty radial locking door for safe operation.
What power supply is required?
The autoclave operates on 440V AC, 3-phase power supply, making it suitable for industrial and institutional installations.
What capacities are available?
The MT-187 Series is available in 78L, 162L, 165L, and 221L capacities.
Which industries commonly use the MT-187 Series?
The Horizontal High Pressure Autoclave is widely used in pharmaceutical industries, hospitals, microbiology laboratories, biotechnology laboratories, universities, research institutes, food testing laboratories, and industrial quality control facilities.
Can the MT-187 Series be supplied in bulk?
Yes. Micro Technologies offers OEM manufacturing, institutional procurement, government tender supply, distributor support, export orders, and bulk industrial supply.
Why Choose Our Products
- Heavy-duty triple-wall construction
- Large-capacity horizontal chamber
- Reliable radial locking mechanism
- Automatic pressure regulation
- Automatic low-water protection
- Continuous industrial operation
- OEM and customized manufacturing
- Competitive pricing
- Bulk supply capability
- Strict quality inspection
- Professional technical support
- Reliable after-sales service
Call to Action
Looking for a reliable Horizontal High Pressure Autoclave (MT-187 Series)? Micro Technologies manufactures and supplies premium horizontal steam sterilizers designed for pharmaceutical industries, hospitals, biotechnology laboratories, universities, research institutes, food testing laboratories, microbiology laboratories, and industrial manufacturing facilities. Contact us today for customized specifications, OEM manufacturing, government tenders, distributor inquiries, bulk orders, or a competitive quotation.
