Worcester Circuit Board
Product Specification Sheet
Worcester Circuit Board
Model Number: MTE-004
The Worcester Circuit Board is an educational electrical training board that enables students to investigate the nature and properties of electricity by constructing simple circuits. The system uses a practical baseboard with spring terminals and multiple battery holders, allowing components to be connected and rearranged for different experiments. It includes lamps, leads, switches, a potentiometer, resistor, electrode support and other electrical accessories required for practical circuit work. The board is suitable for physics and electrical laboratories, colleges, universities and technical education institutes. Micro Technologies supplies practical educational equipment for hands-on electrical and physics training.
Product Specification
The Worcester Circuit Board is a practical educational training system designed to help students investigate the nature and properties of electricity through simple circuit construction. It provides a baseboard arrangement with spring terminals and component connections, allowing learners to build and modify electrical circuits during practical sessions.
The circuit board includes a range of components such as battery holders, lamps, lamp holders, connecting leads, switches, a wire-wound potentiometer and resistor. These components allow students to explore fundamental electrical concepts by creating different circuit arrangements and observing their operation.
The board uses PCB strips with cut-out sections, with connector ends that can be inserted into spring terminals. This arrangement provides convenient connections while allowing students to construct circuits according to the requirements of individual experiments.
The Worcester Circuit Board is suitable for physics practical laboratories, electrical training institutes, colleges, universities and educational facilities. It can support classroom demonstrations as well as hands-on student experiments involving basic electrical circuits and components.
The supplied accessories also include electrode support, pencil lead electrodes, sheet copper foil, steel wool and different types of electrical wire. These components provide additional flexibility for practical investigations and experimental activities.
Micro Technologies provides educational and laboratory equipment for institutions requiring practical training solutions. The Worcester Circuit Board offers an organized platform for introducing students to circuit construction, electrical components and basic electricity experiments.
Features
- Practical baseboard for electrical circuit experiments
- Spring terminals for convenient circuit connections
- Three battery holders
- 1.25 V lamps included
- PCB-mounted lamp holders
- Wire-wound potentiometer with crocodile clip connections
- 3.9 ohm, 2.5 W resistor
- Red, black and yellow connecting leads
- PCB-mounted switches
- Electrode support and pencil lead electrodes
Benefits
- Supports hands-on learning of electricity concepts
- Helps students construct and investigate simple circuits
- Provides multiple components for practical experiments
- Useful for classroom demonstrations and laboratory work
- Makes circuit connections convenient for students
- Suitable for physics and electrical education
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Worcester Circuit Board |
| Product Type | Electrical Training & Experiment Board |
| Baseboard | Plastic |
| Terminals | Spring Terminals |
| Battery Holders | 3 |
| Lamps | 1.25 V M.E.S. |
| Lamp Holders | PCB Connectors |
| Potentiometer | Wire-Wound with Crocodile Clip Connections |
| Resistor | 3.9 Ohm, 2.5 W |
| Switches | PCB-Mounted |
| Connecting Leads | Red, Black & Yellow |
| Electrode Support | Included |
| Pencil Lead Electrodes | Included |
| Copper Foil | 2 m |
| Eureka Wire | 2 m, SWG 34 |
| Copper Wire | 2 m Bare Copper Wire |
| Steel Wool | 1 Pack |
| Instruction Manual | English |
Available Variants
Standard Worcester Circuit Board
Complete practical circuit board configuration with electrical components and accessories.
Institutional Supply
Suitable for schools, colleges, universities and laboratories requiring multiple training boards.
Applications
- Physics laboratories
- Electrical training laboratories
- Electricity practical experiments
- Circuit construction experiments
- School science laboratories
- College and university laboratories
- Technical training institutes
- Electrical education programs
FAQs
What is the Worcester Circuit Board used for?
The Worcester Circuit Board is used to investigate basic electricity concepts by constructing simple electrical circuits. It is suitable for practical teaching and laboratory experiments.
What type of baseboard is provided?
The unit is supplied with a plastic baseboard featuring spring terminals for making electrical connections.
What lamps are included?
The supplied configuration includes 1.25 V M.E.S. lamps with lamp holders mounted on PCB connectors.
Does the board include a potentiometer?
Yes, the set includes a wire-wound potentiometer with crocodile clip connections.
What resistor is included?
The specified resistor is 3.9 ohm, 2.5 W.
Is an instruction manual included?
Yes, an instruction manual in English is included with the equipment.
Why Choose Our Products
- Practical circuit construction and experimentation platform
- Multiple electrical components supplied in one set
- Suitable for physics and electrical education
- Convenient spring-terminal connection system
- Suitable for institutional laboratory requirements
Call to Action
Contact Micro Technologies for pricing, bulk orders and institutional requirements for the Worcester Circuit Board. Request a quotation for electrical and physics laboratory training applications.
