Universal Microcontroller Trainer

The Universal Microcontroller Trainer is a complete embedded development system designed to provide practical training on 8051, PIC16F877, and AVR microcontrollers using a single hardware platform. Manufactured by Micro Technologies, the trainer allows students and professionals to study multiple microcontroller architectures without requiring separate development boards.

Designed for engineering colleges, universities, polytechnic institutes, research laboratories, and technical training centres, the trainer provides an ideal platform for learning embedded programming, digital interfacing, serial communication, and real-time hardware control.

The trainer operates from regulated +12V and +5V DC power supplies and functions on a standard 230V AC, 50Hz mains supply. It supports programming through dedicated programmers for PIC16F877 (USB), AVR (USB), and 8051 (USB), supplied separately.

The development platform integrates numerous onboard peripherals that eliminate the need for external interface modules. These include an optically coupled relay interface, stepper motor driver, buzzer, LED displays, slide switches, multiplexed seven-segment displays, real-time clock, EEPROM, push-button switches, LCD module, analog-to-digital converter, digital-to-analog converter, RS232 serial communication interface, LED matrix display, and a 4 × 4 matrix keyboard.

All experiment points are brought out through 10-pin FRC male connectors, making expansion and external interfacing simple and convenient. The trainer is supplied with software, sample programs, RS232 cable, and complete instructional documentation to simplify practical learning.

Manufactured using a high-quality insulated printed circuit board with clearly printed symbols and circuit layouts, the trainer is enclosed in a durable ABS plastic cabinet, ensuring reliable laboratory performance and long operational life.

Scope of Learning

• Study of 8051 Microcontroller
• Study of PIC16F877 Microcontroller
• Study of AVR Microcontroller
• Embedded System Development
• Digital Input and Output Interfacing
• LCD Programming
• ADC & DAC Applications
• RTC & EEPROM Interfacing
• Matrix Keyboard Programming
• RS232 Communication
• Motor & Relay Control

Onboard Applications

• 2-Bit Optically Coupled Relay Interface
• Buzzer
• Stepper Motor Driver
• 8-Bit LED Display
• 8-Bit Slide Switch
• Four Multiplexed Seven-Segment Displays
• DS1307 Real-Time Clock
• 24C64 EEPROM
• 4-Bit Push Switch
• 16 × 2 LCD
• ADC0808
• DAC0804
• RS232 Serial Communication Interface
• 8 × 8 LED Matrix Display
• 4 × 4 Matrix Keyboard

Features

• Supports 8051, PIC16F877 & AVR Microcontrollers
• Multi-platform embedded development
• USB programming support
• LCD display interface
• Relay and motor control
• ADC and DAC interface
• RTC and EEPROM support
• RS232 communication
• LED matrix display
• Matrix keyboard
• High-quality insulated PCB
• Clearly printed circuit layout
• Fuse protection
• Durable ABS plastic cabinet
• Long operational life

Benefits

• Learn three popular microcontroller families on one platform
• Reduces laboratory equipment cost
• Simplifies embedded programming
• Supports practical hardware interfacing
• Enables real-time application development
• Suitable for engineering education
• Easy hardware expansion
• Reliable laboratory performance
• Excellent teaching aid
• Low maintenance
• Long service life
• Cost-effective embedded training solution

Technical Specifications

Items Supplied

• Universal Microcontroller Trainer
• Instruction Manual
• Software & Program CD
• RS232 Cable
• 10-Pin FRC Male Connectors
• 10-Pin FRC Cable

Optional Accessories

• Desktop Computer
• USB Programmer for PIC16F877
• USB Programmer for AVR
• USB Programmer for 8051

Applications

• Embedded System Laboratories
• Microcontroller Training Centres
• Electronics Engineering Colleges
• Universities
• Polytechnic Institutes
• Technical Training Centres
• Industrial Training Institutes
• Research Laboratories
• Student Projects
• Robotics Applications
• Automation Training
• Embedded Product Development

SKU System

MT-UMT-001

FAQs

What is the Universal Microcontroller Trainer used for?

It is designed for learning 8051, PIC16F877, and AVR microcontroller programming, embedded system development, hardware interfacing, and communication protocols.

Which microcontrollers are supported?

The trainer supports:

• 8051
• PIC16F877
• AVR

Which onboard peripherals are included?

The trainer includes:

• Relay Interface
• Stepper Motor Driver
• LCD
• ADC
• DAC
• RTC
• EEPROM
• RS232 Interface
• LED Matrix
• Seven-Segment Displays
• Matrix Keyboard
• LED Display
• Slide Switches

Are programmers included?

Dedicated USB programmers for PIC16F877, AVR, and 8051 are supported and available separately.

Is the trainer suitable for engineering laboratories?

Yes. It is ideal for engineering colleges, universities, technical institutes, embedded laboratories, and research organisations.

What accessories are supplied with the trainer?

The trainer includes:

• Instruction Manual
• Software & Program CD
• RS232 Cable
• 10-Pin FRC Male Connectors
• 10-Pin FRC Cable

Can the Universal Microcontroller Trainer be supplied in bulk?

Yes. Micro Technologies supplies Universal Microcontroller Trainers to educational institutions, government organisations, research laboratories, OEM projects, distributors, and bulk procurement.
