Soxhlet Extraction Unit Without Glass Parts

The Soxhlet Extraction Unit Without Glass Parts is a laboratory heating system designed for performing multiple Soxhlet extraction procedures simultaneously.

The main body is manufactured from mild steel with an epoxy powder-coated finish, providing a durable construction suitable for routine laboratory use.

The unit is available with three different heating arrangements: mantle type, heater type and hot plate type. This allows laboratories to select the heating configuration most suitable for their extraction procedures.

The heating arrangement is designed to accommodate compatible Soxhlet flasks from approximately 50 ml to 500 ml capacity.

Each heating position is equipped with an individual energy regulator, allowing users to independently adjust the heating intensity according to the extraction requirements of individual samples.

The unit is supplied with vertical and two horizontal rods with clamps to support and securely position compatible Soxhlet extraction glassware during operation.

Models are available with 3-test and 6-test positions. The 3-test configuration has an indicated total rating of approximately 600 watts, while the 6-test configuration has an indicated rating of approximately 1200 watts.

Glass parts are not included as standard and can be supplied separately as an optional accessory.

Key Features

• Designed for Soxhlet extraction
• Supplied without glass parts
• 3-test configuration available
• 6-test configuration available
• Mantle-type heating option
• Heater-type heating option
• Hot-plate-type heating option
• Individual energy regulator for each position
• Suitable for 50–500 ml Soxhlet flasks
• Mild steel body
• Epoxy powder-coated finish
• Vertical supporting rods
• Two horizontal rods
• Supporting clamps included
• Suitable for continuous extraction procedures

Available Configurations

Technical Specifications

Heating Options

Mantle Type

The mantle-type configuration provides controlled heating around compatible extraction flasks and is suitable for routine Soxhlet extraction procedures.

Heater Type

The heater-type configuration provides individual heating stations for compatible Soxhlet flasks and extraction assemblies.

Hot Plate Type

The hot-plate configuration provides an alternative heating arrangement for laboratories requiring plate-based heating.

Working Principle

Sample Preparation

The material to be extracted is placed inside a suitable extraction thimble or sample holder within the Soxhlet apparatus.

Solvent Heating

A suitable solvent is placed in the flask and heated using the selected heating system.

Solvent Vaporization

As the solvent boils, vapour rises through the Soxhlet assembly and reaches the condenser.

Condensation

The vapour is cooled in the condenser and returns to the extraction chamber as liquid solvent.

Extraction Cycle

The condensed solvent contacts the sample and dissolves extractable components. Once the extraction chamber reaches the appropriate level, the solvent containing the extracted material siphons back into the boiling flask.

Repeated Extraction

The evaporation, condensation and siphoning process repeats automatically, providing continuous extraction over multiple cycles.

Individual Energy Control

Separate Energy Regulators

Each heating position is provided with an individual energy regulator, allowing users to adjust heating intensity separately for different extraction positions.

This provides additional flexibility when multiple samples are processed simultaneously.

Benefits

• Multiple samples can be extracted simultaneously
• Choice of three heating systems
• Available in 3-test and 6-test models
• Individual heating control
• Suitable for different flask capacities
• Supports continuous solvent extraction
• Durable powder-coated construction
• Convenient glassware support arrangement
• Suitable for routine laboratory analysis
• Optional glassware available
• Useful for research and quality control
• Suitable for repetitive extraction procedures

Scope of Application

• Soxhlet Extraction
• Solvent Extraction
• Fat Extraction
• Oil Extraction
• Sample Preparation
• Chemical Analysis
• Food Analysis
• Feed Analysis
• Pharmaceutical Analysis
• Research Testing
• Quality Control
• Analytical Laboratory Work

Applications

• Food Testing Laboratories
• Pharmaceutical Laboratories
• Chemical Laboratories
• Analytical Laboratories
• Agricultural Laboratories
• Feed Testing Laboratories
• Research Laboratories
• Quality Control Laboratories
• Universities
• Research Institutes
• Industrial Laboratories
• Research & Development Centers

Items Supplied

• Soxhlet Extraction Heating Unit
• Individual Energy Regulators
• Vertical Support Rods
• Two Horizontal Rods
• Supporting Clamps
• Electrical Connections
• Operating Instructions

Glass parts are not included in the standard unit.

Optional Accessories

• Glass Parts for 3-Test Unit
• Glass Parts for 6-Test Unit
• Soxhlet Extractors
• Condensers
• Extraction Flasks
• Extraction Thimbles
• Replacement Clamps
• Laboratory Support Accessories

Frequently Asked Questions

What is a Soxhlet Extraction Unit?

A Soxhlet Extraction Unit is laboratory equipment used to provide controlled heating and support for continuous solvent extraction using a compatible Soxhlet glassware assembly.

How many test positions are available?

The unit is available in 3-test and 6-test configurations.

What heating options are available?

It can be supplied with mantle-type, heater-type or hot-plate-type heating systems.

What flask sizes can be used?

The specified unit is suitable for compatible Soxhlet flasks ranging from approximately 50 ml to 500 ml.

What is the power rating?

The 3-test model is approximately 600 watts, while the 6-test model is approximately 1200 watts.

Does each position have separate heating control?

Yes. Each heating position is provided with an individual energy regulator.

Are glass parts included?

No. This configuration is supplied without glass parts. Compatible glassware can be ordered separately.

Can glass parts be supplied separately?

Yes. Complete glass parts for both 3-test and 6-test configurations can be supplied as optional accessories.

Can it be used for fat extraction?

Yes. Soxhlet extraction is commonly used for suitable fat and oil extraction procedures in food, feed, agricultural and analytical testing.

What electrical supply is required?

The specified unit operates on approximately 220/230V AC, 50Hz.

Why Choose Micro Technologies?

• 3-test and 6-test models
• Three heating options
• Individual energy regulators
• Supports 50–500 ml flasks
• Durable powder-coated construction
• Complete support rods and clamps
• Optional Soxhlet glassware
• Suitable for analytical laboratories
• Useful for food and chemical testing
• Institutional and bulk supply
• Custom configuration options
• Technical assistance

Call to Action

Choose the Soxhlet Extraction Unit Without Glass Parts from Micro Technologies for efficient multi-position solvent extraction and laboratory analysis. Contact us for 3-test or 6-test models, mantle, heater or hot-plate configurations, compatible glassware, detailed specifications, customization, institutional procurement and bulk orders.
