Round Wire Wound Resistance Coil
Product Specification Sheet
Round Wire Wound Resistance Coil
Model Number: MT-1003
The Round Wire Wound Resistance Coil from Micro Technologies is a compact fixed-resistance component designed for electrical and physics laboratory applications. The MT-1003 Series features a black Bakelite case, wire-wound resistance element, brass screw terminals, and terminal connections for convenient circuit integration. It is available in resistance values from 0.5 Ω to 100 Ω to meet different experimental requirements.
Product Specification
The Round Wire Wound Resistance Coil from Micro Technologies is a laboratory electrical component designed to provide a known fixed resistance in experimental circuits. Its compact construction makes it suitable for resistance measurements, electrical circuit studies, current and voltage experiments, and other laboratory applications requiring specific resistance values.
The MT-1003 Series is housed in a durable black Bakelite round case. The Bakelite enclosure provides electrical insulation and protects the internal wire-wound resistance element while offering a compact design suitable for laboratory bench use.
The internal wire-wound resistance element is designed to provide a specified resistance value for experimental circuit arrangements. Individual models are available with different resistance values, allowing laboratories to select the appropriate unit according to the requirements of a particular circuit or experiment.
The top of the unit is fitted with brass screw terminals, providing convenient connection points for laboratory leads and compatible electrical connectors. The screw-type arrangement enables secure circuit connections while allowing quick installation and removal during practical work.
The MT-1003 Series is available in resistance values of 0.5 Ω, 1 Ω, 2 Ω, 5 Ω, 10 Ω, 20 Ω, 50 Ω, and 100 Ω. This wide selection makes the series suitable for different electrical resistance experiments and circuit configurations.
Manufactured and supplied by Micro Technologies, the Round Wire Wound Resistance Coil is suitable for physics laboratories, electrical laboratories, electronics laboratories, research facilities, testing laboratories, colleges, universities, and other facilities requiring fixed resistance components for experimental circuits.
Features
- Round wire-wound resistance coil
- Black Bakelite case
- Wire-wound resistance element
- Brass screw terminals
- Fixed resistance configuration
- Compact bench-top design
- Eight resistance values available
- Resistance range from 0.5 Ω to 100 Ω
- Convenient circuit connections
- Durable construction
- Suitable for repeated laboratory use
Benefits
- Provides known resistance values for laboratory circuits
- Multiple resistance options meet different experimental requirements
- Bakelite case provides electrical insulation
- Brass screw terminals enable convenient connections
- Compact construction requires minimal bench space
- Simple design allows easy circuit integration
- Suitable for a variety of electrical and physics experiments
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Round Wire Wound Resistance Coil |
| Model Series | MT-1003 Series |
| Product Type | Fixed Laboratory Resistance Coil |
| Shape | Round |
| Case Material | Black Bakelite |
| Resistance Element | Wire Wound |
| Terminal Type | Brass Screw Terminals |
| Minimum Resistance | 0.5 Ω |
| Maximum Resistance | 100 Ω |
| Available Values | 0.5, 1, 2, 5, 10, 20, 50 & 100 Ω |
| Application | Electrical Circuits & Resistance Experiments |
Available Models & Resistance Values
| Model No. | Resistance |
|---|---|
| MT-1003A | 0.5 Ω |
| MT-1003B | 1 Ω |
| MT-1003C | 2 Ω |
| MT-1003D | 5 Ω |
| MT-1003E | 10 Ω |
| MT-1003F | 20 Ω |
| MT-1003G | 50 Ω |
| MT-1003H | 100 Ω |
Applications
- Resistance measurement experiments
- Electrical circuit experiments
- Ohm's law experiments
- Current and voltage studies
- Series circuit experiments
- Parallel circuit experiments
- Electrical testing
- Physics laboratory practicals
- Electronics laboratory experiments
- General circuit demonstrations
Available Variants
0.5 Ohm Resistance Coil, 1 Ohm Resistance Coil, 2 Ohm Resistance Coil, 5 Ohm Resistance Coil, 10 Ohm Resistance Coil, 20 Ohm Resistance Coil, 50 Ohm Resistance Coil, 100 Ohm Resistance Coil, Round Bakelite Resistance Coil, Wire Wound Laboratory Resistance Coil
SKU System
MT-RRC-1003A, MT-RRC-1003B, MT-RRC-1003C, MT-RRC-1003D, MT-RRC-1003E, MT-RRC-1003F, MT-RRC-1003G, MT-RRC-1003H
FAQs
What is a Round Wire Wound Resistance Coil used for?
A Round Wire Wound Resistance Coil is used to introduce a known fixed resistance into an electrical circuit for resistance measurements, circuit experiments, current-voltage studies, and other laboratory applications.
What is the model series of this Resistance Coil?
The Micro Technologies model series for this product is MT-1003 Series.
What resistance values are available?
The series is available in 0.5 Ω, 1 Ω, 2 Ω, 5 Ω, 10 Ω, 20 Ω, 50 Ω, and 100 Ω resistance values.
What type of case is used?
The resistance coil is housed in a round black Bakelite case, providing a compact and electrically insulating enclosure.
What type of terminals are provided?
The MT-1003 Series features brass screw terminals for convenient and secure electrical circuit connections.
Which model has a resistance of 100 Ohm?
The MT-1003H model provides a fixed resistance of 100 Ω.
Which model has a resistance of 0.5 Ohm?
The MT-1003A model provides a fixed resistance of 0.5 Ω.
Why Choose Our Products
- Manufactured and supplied by Micro Technologies
- Multiple resistance values from 0.5 Ω to 100 Ω
- Durable black Bakelite enclosure
- Wire-wound resistance construction
- Brass screw terminal connections
- Suitable for bulk and institutional requirements
- OEM and distributor supply available
