Magnetic Induction Circuit Board
Product Specification Sheet
Magnetic Induction Circuit Board
Model Number: MTME-27
The Magnetic Induction Circuit Board is a complete apparatus designed to demonstrate the fundamentals of magnetic induction and investigate the relationship between magnetic field strength and induced voltage. Micro Technologies supplies the unit with a fixed coil mounted in the board, an acrylic rod, a pair of connecting leads, and a galvanometer. The supplied acrylic rod can be replaced with an iron core to compare how the core material affects magnetic induction and the resulting induced voltage. An instruction manual is also included.
Product Specification
The Magnetic Induction Circuit Board is designed for practical investigation of electromagnetic induction and the relationship between a changing magnetic field and the voltage induced in a coil. Its integrated construction provides a convenient arrangement for performing comparative magnetic-induction experiments.
The apparatus incorporates a fixed coil mounted securely in the board. When the magnetic environment of this coil changes, an induced electrical response can be observed using the supplied galvanometer.
Micro Technologies supplies an acrylic rod for use with the coil. Because acrylic is non-magnetic, it provides a useful reference configuration for comparing the behaviour of the circuit with a magnetic core.
The acrylic rod can be replaced by an iron core. Introducing an iron core changes the magnetic conditions within the coil and allows users to investigate the relationship between magnetic field strength and induced voltage.
A galvanometer is included for detecting the induced electrical response. Its deflection provides a visible indication of the induced current and can also be used to observe changes in direction under different experimental conditions.
A pair of connecting leads is supplied to simplify circuit connections between the board and the measuring instrument. The complete configuration minimizes the need for additional basic accessories during setup.
The apparatus can support experiments involving magnetic induction, electromagnetic induction, magnetic flux changes, induced voltage, core-material effects, and the relationship between magnetic-field variation and electrical response.
The inclusion of both acrylic and iron core configurations provides a convenient way to compare the influence of different core materials within the same experimental setup.
With its fixed induction coil, interchangeable core arrangement, galvanometer, connecting leads, and supplied instruction manual, the Magnetic Induction Circuit Board provides a complete and reusable setup for electromagnetism investigations.
Features
- Complete magnetic induction apparatus
- Fixed coil mounted in the board
- Acrylic rod supplied
- Iron core supplied
- Interchangeable core arrangement
- Galvanometer included
- Pair of connecting leads included
- Demonstrates magnetic induction
- Investigates induced voltage
- Allows comparison of different core materials
- Suitable for magnetic-field strength investigations
- Integrated bench-top construction
- Instruction manual included
- Reusable experimental apparatus
Benefits
- Provides a complete setup for magnetic induction experiments
- Demonstrates the relationship between magnetic field and induced voltage
- Acrylic and iron cores enable comparative investigations
- Galvanometer provides clear indication of induced electrical response
- Fixed coil maintains consistent experimental geometry
- Supplied leads simplify circuit connections
- Integrated design reduces setup time
- Suitable for repeated electromagnetism experiments
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Magnetic Induction Circuit Board |
| Internal Model No. | MT-41157 |
| Product Type | Magnetic Induction Experiment Apparatus |
| Coil Arrangement | Fixed in Board |
| Acrylic Rod | Included |
| Iron Core | Included |
| Core Arrangement | Interchangeable |
| Connecting Leads | 1 Pair Included |
| Measuring Instrument | Galvanometer Included |
| Instruction Manual | Included |
| Primary Investigation | Magnetic Field Strength & Induced Voltage |
| Secondary Application | Core Material Comparison |
| Usage / Application | Magnetic induction & electromagnetism experiments |
Components Included
| Component | Quantity / Details |
|---|---|
| Magnetic Induction Circuit Board | 1 |
| Fixed Coil | Mounted on Board |
| Acrylic Rod | 1 |
| Iron Core | 1 |
| Connecting Leads | 1 Pair |
| Galvanometer | 1 |
| Instruction Manual | 1 |
Applications
- Magnetic induction experiments
- Electromagnetic induction investigations
- Induced voltage experiments
- Magnetic-field strength investigations
- Comparison of acrylic and iron cores
- Magnetic flux experiments
- Galvanometer deflection experiments
- Electromagnetism laboratory investigations
Available Variants
- MT-41157 – Standard Magnetic Induction Circuit Board
- Magnetic Induction Board with Galvanometer
- Electromagnetic Induction Experiment Apparatus
- Magnetic Induction Apparatus with Interchangeable Cores
- Customized configurations for bulk requirements
SKU System
- MT-MICB-STD – Standard Magnetic Induction Circuit Board
- MT-MICB-CORE – Interchangeable Core Configuration
- MT-MICB-GAL – Configuration with Galvanometer
- MT-MICB-IND – Magnetic Induction Configuration
- MT-MICB-CUS – Customized Configuration
FAQs
What is a Magnetic Induction Circuit Board used for?
It is used to demonstrate magnetic induction and investigate the relationship between magnetic-field strength and induced voltage.
Is a coil included with the apparatus?
Yes. A coil is fixed securely in the board as part of the apparatus.
Which core materials are supplied?
The apparatus includes an acrylic rod and an iron core for comparative experiments.
Why is an acrylic rod used?
The acrylic rod provides a non-magnetic reference configuration that can be compared with the magnetic behaviour obtained when an iron core is inserted.
Can the acrylic rod be replaced with an iron core?
Yes. The apparatus is specifically designed to allow the acrylic rod to be replaced by the supplied iron core.
What is investigated by changing the core?
Changing the core allows the effect of core material on magnetic conditions and the resulting induced electrical response to be investigated.
Is a galvanometer supplied?
Yes. A galvanometer is included with the standard apparatus.
What is the purpose of the galvanometer?
The galvanometer detects the induced current and provides a visible indication of the electrical response generated during magnetic-induction experiments.
Are connecting leads included?
Yes. One pair of connecting leads is supplied.
Is an instruction manual included?
Yes. The apparatus is supplied with an instruction manual.
Can the apparatus demonstrate electromagnetic induction?
Yes. It is designed for experiments involving magnetic induction, changing magnetic conditions, and the resulting induced electrical response.
Can Magnetic Induction Circuit Boards be supplied in bulk?
Yes. Micro Technologies can supply these apparatus in bulk for laboratories, universities, colleges, research facilities, scientific equipment distributors, and institutional procurement.
