LPC2148 Microcontroller Trainer

The LPC2148 Microcontroller Trainer is a complete embedded development system designed to evaluate and demonstrate the capabilities of the NXP LPC2148 ARM7 microcontroller. Manufactured by Micro Technologies, the trainer provides an advanced platform for learning embedded programming, hardware interfacing, and real-time application development.

The development board is intended for general-purpose embedded applications and integrates numerous onboard peripherals, eliminating the need for additional interfacing hardware. It is ideally suited for engineering colleges, universities, polytechnic institutes, research laboratories, and embedded system training centres.

The trainer operates from regulated +12V and +5V DC power supplies and functions on a standard 230V AC, 50Hz mains supply. Programming is carried out using a dedicated LPC2148 programmer, available separately.

The trainer features a wide range of integrated peripherals including an optically coupled relay interface, stepper motor driver, buzzer, LED displays, DIP switches, tactile switches, reset boot loader circuit, real-time clock, EEPROM, matrix keyboard, LED matrix display, serial communication interface, SD card interface, LCD, graphical LCD, RS232 communication, and an audio section.

The 128 × 64 graphical LCD enables development of advanced graphical applications, while the SD card interface supports external memory and data logging projects. Multiple display and communication interfaces make the trainer suitable for real-time embedded system development and industrial automation experiments.

The front panel is manufactured using a high-quality insulated printed circuit board with clearly printed symbols and circuit layouts. All experiment points are available through 10-pin FRC connectors for convenient expansion and external interfacing.

The trainer is housed in a durable ABS plastic cabinet, ensuring reliable laboratory performance and long operational life.

Scope of Learning

• Study of LPC2148 ARM7 Development System
• ARM7 Microcontroller Programming
• Embedded System Development
• Digital Input and Output Interfacing
• LCD and Graphical LCD Programming
• Serial Communication
• SD Card Interfacing
• RTC and EEPROM Applications
• Motor Control
• Relay Control
• Embedded Peripheral Interfacing

Onboard Applications

• 2-Bit Optically Coupled Relay Interface
• Buzzer
• Stepper Motor Driver
• 8-Bit LED Display
• 8-Bit DIP Switch
• 6-Bit Tact Switch Interface
• Reset Boot Loader Circuit
• Four Multiplexed Seven-Segment Displays
• DS1307 Real-Time Clock
• 24C64 EEPROM
• 4 × 4 Matrix Keyboard
• 8 × 8 LED Matrix Display
• Serial to Serial Interface
• SD Card Interface
• 4-Bit Push Switch
• 16 × 2 LCD
• RS232 Serial Communication Interface
• Audio Section
• 128 × 64 Graphical LCD

Features

• ARM7 LPC2148 development platform
• Multiple onboard peripherals
• Graphical LCD support
• SD card interface
• Relay and motor control
• LCD and LED display modules
• RTC and EEPROM interfaces
• RS232 communication
• Matrix keyboard interface
• LED matrix display
• Audio interface
• Boot loader support
• High-quality insulated PCB
• Clearly printed circuit layout
• Durable ABS plastic cabinet
• Long operational life

Benefits

• Supports advanced ARM7 programming
• Simplifies embedded application development
• Reduces external interfacing requirements
• Suitable for industrial automation projects
• Enables real-time embedded experiments
• Supports graphical display applications
• Easy hardware expansion
• Reliable laboratory performance
• Excellent teaching aid
• Low maintenance
• Cost-effective embedded development platform
• Long service life

Technical Specifications

Items Supplied

• LPC2148 Microcontroller Trainer
• Instruction Manual
• CD Containing Software and Programs
• RS232 Cable
• 10-Pin FRC Male Connectors
• 10-Pin FRC Cable

Optional Accessories

• LPC2148 Programmer

Applications

• ARM7 Development Laboratories
• Embedded System Laboratories
• Electronics Engineering Colleges
• Universities
• Polytechnic Institutes
• Technical Training Centres
• Research Laboratories
• Industrial Automation Training
• Embedded Product Development
• Student Projects
• Robotics Applications
• Embedded Control Systems

SKU System

MT-LPC2148-001

FAQs

What is the LPC2148 Microcontroller Trainer used for?

It is used for learning ARM7 embedded programming, peripheral interfacing, real-time application development, and embedded system design using the LPC2148 microcontroller.

Which onboard peripherals are included?

The trainer includes relay interface, stepper motor driver, LCD, graphical LCD, SD card interface, RTC, EEPROM, RS232 communication, LED displays, keypad, LED matrix, audio section, and several digital input/output interfaces.

Does the trainer support graphical display applications?

Yes. It features a 128 × 64 Graphical LCD, enabling advanced graphical interface development.

Is SD card interfacing available?

Yes. An onboard SD Card Interface is provided for data logging and external memory applications.

Is a programmer supplied with the trainer?

The LPC2148 Programmer is available separately as an optional accessory.

What accessories are supplied with the trainer?

The trainer includes:

• Instruction Manual
• Software and Program CD
• RS232 Cable
• 10-Pin FRC Male Connectors
• 10-Pin FRC Cable

Is the trainer suitable for engineering laboratories?

Yes. It is ideal for engineering colleges, universities, polytechnic institutes, embedded laboratories, technical training centres, and research organisations.

Can the LPC2148 Microcontroller Trainer be supplied in bulk?

Yes. Micro Technologies supplies LPC2148 Microcontroller Trainers to educational institutions, government organisations, research laboratories, OEM projects, distributors, and bulk procurement.
