LDR Characteristics Apparatus (Analog Meters)
Product Specification Sheet
LDR Characteristics Apparatus (Analog Meters)
Model Number: MT-E098A
The LDR Characteristics Apparatus (Analog Meters) is a precision laboratory instrument designed for studying the voltage-current (V-I) characteristics of Light Dependent Resistors (LDRs). Manufactured by Micro Technologies, it features analog meters, a regulated DC power supply, a dedicated optical setup, and a precision optical bench for semiconductor experiments.
Product Specification
The LDR Characteristics Apparatus (Analog Meters) is a laboratory trainer developed for studying the V-I characteristics of a Light Dependent Resistor (LDR) under different illumination conditions. Manufactured by Micro Technologies, the apparatus enables students to investigate the relationship between light intensity and electrical resistance through practical laboratory experiments.
Designed for engineering colleges, universities, polytechnic institutes, technical training centres, and electronics laboratories, the apparatus provides a complete experimental setup with analog measuring instruments, regulated power supply, and an adjustable optical arrangement for accurate observation.
The trainer incorporates a regulated 0–10V DC power supply that delivers stable voltage for the experiment. Built-in analog voltmeter and analog ammeter enable precise monitoring of voltage and current during LDR characteristic studies.
A dedicated LDR unit is mounted on a wooden optical bench with engraved scale, allowing accurate positioning relative to the 100W light source. The applied voltage is controlled using an onboard precision potentiometer, enabling smooth variation of voltage while observing changes in LDR resistance.
The apparatus also supports optional colour filters for studying spectral response and an optional lux meter for measuring illumination intensity. Manufactured using a high-quality insulated printed circuit board with clearly printed circuit symbols, the trainer is housed in a durable ABS plastic cabinet. All experimental terminals are brought out through 4 mm colour-coded sockets for safe and reliable laboratory operation.
Scope of Learning
- Study of V-I Characteristics of Light Dependent Resistor (LDR)
- Effect of Light Intensity on Resistance
- Optical Sensor Characteristics
- Semiconductor Device Behaviour
- Spectral Response of LDR
- Analog Electronics Experiments
- Practical Sensor Measurements
- Electronics Laboratory Techniques
Features
- Built-in analog voltmeter and ammeter
- Regulated DC power supply
- Dedicated LDR unit
- 100W light source
- Wooden optical bench with engraved scale
- Precision voltage control
- Colour-coded 4 mm sockets
- High-quality insulated PCB
- Clearly printed circuit layout
- Rugged ABS plastic cabinet
- Laboratory-grade construction
- Long operational life
Benefits
- Accurate LDR characteristic measurements
- Stable regulated power supply
- Easy optical alignment
- Reliable laboratory performance
- Suitable for engineering education
- Safe laboratory operation
- Durable construction
- Simple experimental setup
- Low maintenance
- Long service life
- Cost-effective laboratory solution
- Ideal for semiconductor and sensor studies
Technical Specifications
| Specification | Details |
|---|---|
| Product Name | LDR Characteristics Apparatus (Analog Meters) |
| Experiment | V-I Characteristics of LDR |
| Voltmeter | Analog 6V DC |
| Ammeter | Analog 10mA / 100µA DC |
| Power Supply | Regulated 0–10V DC, 150mA |
| Input Supply | 230V AC, 50Hz ±10% |
| LDR Unit | Separate Optical Unit |
| Light Source | 100W Bulb |
| Optical Bench | Wooden Bench with Engraved Scale |
| Voltage Control | Precision Potentiometer |
| Connection Sockets | 4 mm Colour-Coded |
| Cabinet | ABS Plastic |
| Approximate Size | 12" × 8" |
Items Supplied
- LDR Characteristics Apparatus (Analog Meters)
- Optical LDR Unit
- Wooden Optical Bench
- 100W Light Source
- Instruction Manual
- 4 mm Patch Cords
Optional Accessories
- Colour Filter Set (Spectral Characteristics)
- Lux Meter
Applications
- Electronics Engineering Laboratories
- Semiconductor Physics Laboratories
- Sensor Technology Laboratories
- Engineering Colleges
- Universities
- Polytechnic Institutes
- Technical Training Centres
- Research Laboratories
- Educational Demonstrations
- Student Practical Experiments
SKU System
MT-LDRA-001
FAQs
What is the LDR Characteristics Apparatus (Analog Meters) used for?
It is used to study the voltage-current (V-I) characteristics of a Light Dependent Resistor (LDR) and analyze its behaviour under different illumination levels.
Which measuring instruments are included?
The apparatus includes:
- Analog 6V DC Voltmeter
- Analog 10mA / 100µA DC Ammeter
What light source is provided?
The apparatus includes a 100W light source for controlled illumination during experiments.
How is the applied voltage controlled?
The applied voltage is adjusted using an onboard precision potentiometer.
What optional accessories are available?
The following optional accessories are available:
- Colour Filter Set (for spectral response studies)
- Lux Meter
Is the apparatus suitable for engineering laboratories?
Yes. It is ideal for engineering colleges, universities, polytechnic institutes, technical training centres, and electronics laboratories.
Can the LDR Characteristics Apparatus (Analog Meters) be supplied in bulk?
Yes. Micro Technologies supplies LDR Characteristics Apparatus (Analog Meters) to educational institutions, government organisations, research laboratories, OEM projects, distributors, and bulk procurement.
