Laboratory Fume Hood (Stainless Steel & Mild Steel) (MT-114 Series)
Product Specification Sheet
Laboratory Fume Hood (Stainless Steel & Mild Steel) (MT-114 Series)
Model Number: MTFH-01
The Laboratory Fume Hood (Stainless Steel & Mild Steel) (MT-114 Series) is a high-performance chemical exhaust enclosure designed to safely remove hazardous fumes, vapors, gases, and airborne contaminants generated during laboratory operations. Manufactured by Micro Technologies, it features robust SS304 or powder-coated mild steel construction, a chemical-resistant work surface, efficient exhaust ventilation, and multiple customization options for laboratories, research centers, pharmaceutical industries, and educational institutions.
Product Specification
The Laboratory Fume Hood (Stainless Steel & Mild Steel) (MT-114 Series) is engineered to provide a safe and controlled working environment for laboratory personnel handling hazardous chemicals, corrosive substances, acids, alkalis, solvents, and volatile compounds. Manufactured by Micro Technologies, the hood effectively captures and exhausts toxic vapors before they enter the laboratory environment, protecting both personnel and sensitive laboratory equipment.
Available in SS304 stainless steel or powder-coated mild steel construction, the MT-114 Series offers exceptional durability, corrosion resistance, and long service life. The interior chamber is finished with a smooth epoxy-coated surface to withstand continuous exposure to aggressive laboratory chemicals while allowing quick and easy cleaning.
The hood is equipped with a counter-balanced vertically sliding front sash that provides convenient access to the work area while helping maintain safe airflow during operation. A chemical-resistant worktop is supplied as standard, ensuring excellent resistance against acids, alkalis, and laboratory reagents. An integrated sink with water inlet and outlet connections enables washing and disposal operations directly inside the hood.
Efficient air extraction is achieved through a powerful exhaust system that continuously removes hazardous fumes from the working chamber. For installations requiring long exhaust ducting, an optional high-capacity centrifugal exhaust blower can be supplied to maintain optimum airflow performance.
The control panel is ergonomically positioned on the front fascia and incorporates switches for lighting and exhaust operation. Bright fluorescent or LED illumination provides excellent visibility inside the chamber, while integrated utility sockets simplify the operation of laboratory instruments. Remote-controlled service valves for gas, water, air, vacuum, and nitrogen can also be installed according to laboratory requirements.
The MT-114 Series is widely used in pharmaceutical laboratories, chemical laboratories, biotechnology facilities, research institutes, educational institutions, petrochemical industries, environmental testing laboratories, hospitals, forensic laboratories, and industrial quality control departments.
Manufactured by Micro Technologies, every Laboratory Fume Hood is subjected to rigorous inspection for structural strength, airflow performance, electrical safety, and operational reliability before delivery.
Features
- Available in SS304 or powder-coated mild steel construction
- Chemical-resistant interior finish
- Counter-balanced vertical sliding front sash
- Acid and alkali resistant work surface
- Integrated laboratory sink
- Water inlet and outlet connections
- Efficient chemical exhaust system
- Bright fluorescent/LED illumination
- Front-mounted electrical control panel
- Utility power socket
- Remote gas, air, vacuum, nitrogen, and water service valves
- Low-noise operation
- Durable corrosion-resistant construction
- Easy cleaning and maintenance
- Available in multiple working sizes
- Suitable for continuous laboratory operation
Benefits
- Removes hazardous chemical fumes effectively
- Protects laboratory personnel
- Prevents exposure to toxic vapors
- Maintains a safe laboratory environment
- Chemical-resistant work surface
- Durable long-life construction
- Convenient utility connections
- Improved laboratory productivity
- Easy operation and maintenance
- Suitable for pharmaceutical and research laboratories
- Multiple customization options
- Reliable long-term performance
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Laboratory Fume Hood |
| Model Series | MT-114 |
| Construction Options | SS304 Stainless Steel / Powder-Coated Mild Steel |
| Interior Finish | Chemical-Resistant Epoxy Coating |
| Sash Type | Counter-Balanced Vertical Sliding Glass |
| Work Surface | Acid & Alkali Resistant |
| Sink | Chemical-Resistant Sink |
| Water Connection | Inlet & Outlet Provided |
| Exhaust System | Ducted Chemical Exhaust |
| Lighting | Fluorescent / LED |
| Electrical Supply | 220V AC, 50 Hz |
| Utility Socket | 15A Electrical Socket |
| Control Panel | Front Mounted |
| Applications | Chemical Laboratories, Pharmaceutical Industries, Biotechnology, Research Institutes, Educational Laboratories |
Available Models
| Model | Working Chamber |
|---|---|
| MT-114(A) | 2' × 2' × 2' |
| MT-114(B) | 3' × 2' × 2' |
| MT-114(C) | 4' × 2' × 2' |
| MT-114(D) | 6' × 2' × 2' |
Optional Accessories
- High-capacity centrifugal exhaust blower (recommended for duct lengths above 10 ft)
- PVC ducting system
- PP centrifugal fan
- Granite worktop
- Stainless steel worktop
- Remote control taps for water
- Remote control taps for gas
- Remote control taps for compressed air
- Remote control taps for vacuum
- Remote control taps for nitrogen and specialty gases
- LED lighting upgrade
- Airflow monitor
- Magnehelic pressure gauge
- Digital airflow controller
- Chemical-resistant storage cabinet
- Replacement filters (where applicable)
SKU System
- MT-114-A
- MT-114-B
- MT-114-C
- MT-114-D
FAQs
What is the MT-114 Laboratory Fume Hood used for?
The MT-114 Series is designed for safely handling chemicals, acids, alkalis, solvents, toxic vapors, and hazardous laboratory reactions while protecting laboratory personnel from harmful fumes.
What construction materials are available?
The fume hood is available in SS304 stainless steel and powder-coated mild steel construction to suit different laboratory environments and budgets.
Is the work surface resistant to chemicals?
Yes. The worktop is specially designed to resist acids, alkalis, and commonly used laboratory chemicals.
Does the hood include a sink?
Yes. Each MT-114 Series fume hood is equipped with a chemical-resistant sink complete with water inlet and outlet connections.
Can additional utility services be installed?
Yes. Optional remote-controlled service valves for water, gas, compressed air, nitrogen, vacuum, and specialty gases can be incorporated.
Is a high-capacity exhaust fan available?
Yes. A high-capacity centrifugal exhaust system is available for installations where duct lengths exceed approximately 10 feet.
Which industries commonly use the MT-114 Series?
The MT-114 Series is widely used in pharmaceutical industries, chemical laboratories, research institutes, biotechnology companies, universities, environmental laboratories, hospitals, petrochemical plants, and industrial quality control laboratories.
Can the MT-114 Series be customized?
Yes. Micro Technologies offers customized working sizes, utility arrangements, worktop materials, exhaust configurations, storage cabinets, and other options according to customer requirements.
Why Choose Our Products
- Premium SS304 and mild steel construction options
- Efficient chemical fume extraction
- Chemical-resistant interior and work surface
- Smooth counter-balanced sliding sash
- Multiple utility service options
- High-quality exhaust performance
- Available in customized sizes
- OEM manufacturing support
- Competitive B2B pricing
- Strict quality inspection
- Reliable technical support
- Excellent after-sales service
Call to Action
Choose the Laboratory Fume Hood (Stainless Steel & Mild Steel) (MT-114 Series) from Micro Technologies for safe chemical handling, effective fume extraction, and reliable laboratory ventilation. Contact us today for pricing, customized dimensions, utility configurations, OEM manufacturing, government tenders, distributor inquiries, or a competitive quotation.
