Inclined Plane with Force Mechanism
Model Number: MTM-107
The Inclined Plane with Force Mechanism from Micro Technologies is designed for experiments involving force and acceleration. The MT-10580 features a 1.2 m long aluminium track, permanently mounted spring force mechanism with multi-position trigger, three steel balls and two irregular-shaped wooden blocks for investigating acceleration, speed and distance under variable applied force.
Product Specification
The Inclined Plane with Force Mechanism from Micro Technologies is a mechanics laboratory apparatus specially designed for practical experiments involving the relationship between force, acceleration, speed, distance and motion.
The MT-10580 incorporates an approximately 1.2 metre long aluminium track that provides an extended path for observing and measuring the motion of test objects.
A specially designed spring-based force mechanism is permanently mounted at one end of the track. The mechanism can apply force to a test object and launch it along the track under controlled experimental conditions.
The spring mechanism incorporates a multi-position trigger, enabling different levels of spring compression and therefore different applied-force conditions to be selected. This allows users to compare how variation in applied force influences the resulting acceleration and motion of an object.
According to Newton's Second Law of Motion:
F = ma
where F represents net force,m is the mass of the moving object and a is its acceleration.
For a given mass, increasing the applied net force generally produces greater acceleration. By changing the spring setting and observing the resulting motion, the apparatus provides a practical method for investigating this relationship.
Users can also determine or compare acceleration, speed and distance attained under variable force conditions. Suitable timing and distance measurements can be incorporated into the experiment depending on the required procedure.
The track is mounted on a three-plastic-feet support arrangement, providing stable positioning during experiments.
The apparatus is supplied with five steel balls and two irregular-shaped wooden blocks, expanding the range of force and motion investigations that can be performed. Different objects can be compared to observe how mass, shape and rolling or sliding behaviour influence their response to an applied force.
This apparatus is particularly useful for investigations involving Newton's laws of motion, force versus acceleration, variable-force launching, linear motion, velocity and displacement.
Manufactured and supplied by Micro Technologies, the Inclined Plane with Force Mechanism provides a versatile platform for physics, mechanics and dynamics laboratories requiring repeatable force-and-motion experiments.
Features
- Inclined plane with integrated force mechanism
- Model MT-10580
- Approximately 1.2 m long aluminium track
- Spring-based force mechanism
- Force mechanism permanently mounted at one end
- Multi-position spring trigger
- Variable applied-force settings
- Suitable for acceleration experiments
- Supports speed and distance investigations
- Three plastic support feet
- Five steel balls included
- Two irregular-shaped wooden blocks included
- Robust mechanical construction
- Suitable for repeated experimental use
- Mechanical operation
Benefits
- Demonstrates the relationship between force and acceleration
- Variable spring settings enable comparative experiments
- Long 1.2 m track provides sufficient travel distance for motion observations
- Supports acceleration, speed and displacement measurements
- Multiple steel balls allow repeated and comparative trials
- Wooden blocks expand the range of motion investigations
- Helps demonstrate Newton's laws experimentally
- Stable support arrangement improves consistency
- Integrated launcher simplifies experimental setup
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Inclined Plane with Force Mechanism |
| Model No. | MT-10580 |
| Product Type | Force & Acceleration Apparatus |
| Track Material | Aluminium |
| Track Length | Approx. 1.2 m |
| Force Mechanism | Spring Based |
| Mechanism Position | Permanently Mounted at One End |
| Trigger | Multi-Position |
| Applied Force | Variable |
| Support | Three Plastic Feet |
| Steel Balls | 5 Included |
| Wooden Blocks | 2 Included |
| Wooden Block Shape | Irregular |
| Acceleration Study | Supported |
| Speed Study | Supported |
| Distance Study | Supported |
| Operation | Mechanical |
Supplied Components
| Component | Details |
|---|---|
| Aluminium Track | Approx. 1.2 m |
| Spring Force Mechanism | Included |
| Multi-Position Trigger | Included |
| Steel Balls | 5 |
| Irregular Wooden Blocks | 2 |
| Plastic Support Feet | 3 |
| Operating Instructions | Included |
Available Model
| Model No. | Product |
|---|---|
| MT-10580 | Inclined Plane with Force Mechanism |
Applications
- Force and acceleration experiments
- Newton's Second Law investigations
- Variable-force experiments
- Linear-motion investigations
- Speed measurements
- Acceleration measurements
- Distance and displacement experiments
- Spring-force investigations
- Rolling-motion experiments
- Comparative object-motion tests
- Mechanics laboratory experiments
- Dynamics experiments
Available Variants
Inclined Plane with Force Mechanism, Force and Acceleration Track, Spring Force Track Apparatus, Variable Force Apparatus, Aluminium Motion Track, Spring Launcher Mechanics Track, Acceleration Experiment Track, Force and Motion Apparatus
SKU System
MT-IPFM-10580
FAQs
What is the MT-10580 Inclined Plane with Force Mechanism used for?
The apparatus is designed for experiments involving force, acceleration, speed, distance and linear motion under different applied-force conditions.
What is the length of the track?
The apparatus features an approximately 1.2 metre long aluminium track.
How is force applied to the test object?
A spring-based force mechanism permanently mounted at one end of the track applies the launching force.
Can the applied force be varied?
Yes. The spring mechanism incorporates a multi-position trigger, allowing different force settings to be selected for comparative experiments.
How many steel balls are supplied?
The apparatus is supplied with five steel balls.
Are wooden blocks included?
Yes. Two irregular-shaped wooden blocks are supplied with the apparatus.
What measurements can be investigated?
The apparatus can support investigations involving acceleration, speed, distance and the effect of variable applied force.
Can Newton's Second Law be demonstrated?
Yes. The apparatus provides a practical setup for investigating the relationship F = ma, particularly how changing applied force influences acceleration.
Does the apparatus require electrical power?
The basic force mechanism is mechanically spring operated and does not require an electrical supply for launching the test objects.
Why Choose Our Products
- Manufactured and supplied by Micro Technologies
- Model MT-10580
- 1.2 m aluminium experimental track
- Integrated spring force mechanism
- Multi-position force adjustment
- Five steel balls supplied
- Two irregular wooden blocks included
- Suitable for multiple force and motion investigations
- Institutional, OEM, bulk and distributor supply available
Call to Action
Choose the Inclined Plane with Force Mechanism – MT-10580 from Micro Technologies for practical experiments involving force, acceleration, speed and linear motion. Contact us for competitive pricing, institutional procurement, bulk orders, OEM requirements, distributor supply and customized quotations.
