Humidity Cabinet (MT-190 Series)
Product Specification Sheet
Humidity Cabinet (MT-190 Series)
Model Number: MTHC-01
The Humidity Cabinet (MT-190 Series) is a precision environmental chamber designed for accurate humidity and temperature-controlled testing. Manufactured by Micro Technologies, the cabinet provides a temperature range from 5°C above ambient to 60°C with 30–90% relative humidity, making it ideal for seed germination, biological research, pharmaceutical testing, stability studies, material testing, and quality control laboratories.
Product Specification
The Humidity Cabinet (MT-190 Series) is a high-performance environmental testing chamber developed to provide accurate humidity and temperature control for laboratory, pharmaceutical, agricultural, industrial, and research applications. Manufactured by Micro Technologies, the cabinet is designed to maintain stable environmental conditions required for product testing, biological studies, seed storage, stability analysis, and quality assurance.
The cabinet maintains a temperature range from 5°C above ambient to 60°C, while providing controlled relative humidity between 30% and 90%, making it suitable for a wide variety of laboratory applications requiring controlled climatic conditions.
The MT-190 Series is manufactured using high-quality insulated construction that minimizes heat loss and ensures uniform temperature and humidity distribution throughout the chamber. The interior is designed to accommodate laboratory samples safely while providing consistent environmental conditions for accurate and repeatable testing.
Multiple chamber capacities are available to meet different laboratory requirements, ranging from 95 litres to 335 litres. The cabinet is suitable for pharmaceutical stability studies, biological culture work, agricultural research, seed testing, food storage studies, environmental testing, and industrial quality control.
For enhanced operational accuracy, the cabinet can be supplied with a digital hygrometer, digital temperature indicator-cum-controller, microprocessor PID temperature controller, and a fully automatic electronic temperature and humidity controller with digital display.
To ensure uninterrupted operation under fluctuating power conditions, an automatic 3 kVA voltage stabilizer is recommended.
Manufactured by Micro Technologies, every Humidity Cabinet undergoes stringent quality inspection to ensure reliable environmental control, accurate humidity regulation, and long service life. The MT-190 Series is widely used in pharmaceutical industries, biotechnology laboratories, agricultural research centres, universities, seed testing laboratories, food testing laboratories, hospitals, research institutes, and industrial quality control facilities.
Features
- Precision humidity cabinet
- Temperature range 5°C above ambient to 60°C
- Relative humidity range 30–90% RH
- Uniform temperature distribution
- Uniform humidity distribution
- Heavy-duty insulated cabinet
- Multiple chamber capacities
- Corrosion-resistant construction
- Energy-efficient operation
- Stable environmental control
- Continuous-duty laboratory operation
- Easy operation and maintenance
- Heavy-duty laboratory construction
- Long operational life
Benefits
- Accurate humidity and temperature control
- Ideal for pharmaceutical stability studies
- Reliable environmental testing
- Uniform chamber conditions
- Suitable for continuous laboratory operation
- Durable laboratory construction
- Low maintenance requirements
- Energy-efficient performance
- Repeatable test results
- Long service life
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Humidity Cabinet (MT-190 Series) |
| Product Type | Laboratory Humidity Chamber |
| Temperature Range | 5°C Above Ambient to 60°C |
| Humidity Range | 30–90% RH |
| Construction | Heavy-Duty Insulated Cabinet |
| Environmental Control | Temperature & Humidity |
| Power Supply | 220–230V AC, 50Hz |
| Applications | Stability Testing, Seed Testing, Biological Research, Pharmaceutical Testing, Environmental Studies |
Available Models
| Model | Chamber Size (W × D × H) | Capacity |
|---|---|---|
| MT-190(A) | 455 × 455 × 455 mm | 95 Litres |
| MT-190(B) | 455 × 455 × 710 mm | 147 Litres |
| MT-190(C) | 605 × 605 × 605 mm | 225 Litres |
| MT-190(D) | 605 × 605 × 910 mm | 335 Litres |
Optional Accessories
- Hygrometer (Humidity Indicator)
- Digital Temperature Indicator-cum-Controller
- Microprocessor PID Digital Temperature Controller
- Automatic Electronic Temperature & Humidity Controller with Digital Display
- Automatic 3 kVA Voltage Stabilizer (Recommended)
- Adjustable Stainless Steel Shelves
- Data Logger
- Calibration Certificate
SKU System
- MT-190-A
- MT-190-B
- MT-190-C
- MT-190-D
FAQs
What is the MT-190 Humidity Cabinet used for?
The MT-190 Series is used for humidity and temperature-controlled testing in pharmaceutical laboratories, seed testing, biological research, stability studies, food testing, and industrial quality control.
What is the operating temperature range?
The cabinet operates from 5°C above ambient to 60°C.
What humidity range does the cabinet provide?
The MT-190 Series provides controlled humidity from 30% to 90% RH.
What chamber capacities are available?
The cabinet is available in 95L, 147L, 225L, and 335L capacities.
What optional controllers are available?
Optional accessories include a digital hygrometer, digital temperature indicator-cum-controller, microprocessor PID controller, and a fully automatic electronic temperature and humidity controller.
Is a voltage stabilizer recommended?
Yes. An automatic 3 kVA voltage stabilizer is recommended to ensure stable operation and protect the equipment from voltage fluctuations.
Which industries commonly use the MT-190 Series?
The Humidity Cabinet is widely used in pharmaceutical industries, biotechnology laboratories, agricultural research centres, universities, seed testing laboratories, food testing laboratories, hospitals, research institutes, and industrial quality control facilities.
Can the MT-190 Series be supplied in bulk?
Yes. Micro Technologies offers OEM manufacturing, institutional procurement, government tender supply, distributor support, export orders, and bulk industrial supply.
Why Choose Our Products
- Precision humidity and temperature control
- Wide environmental operating range
- Heavy-duty insulated construction
- Multiple chamber capacities
- Advanced controller options
- Reliable laboratory performance
- OEM and customized manufacturing
- Competitive pricing
- Bulk supply capability
- Strict quality inspection
- Professional technical support
- Reliable after-sales service
Call to Action
Looking for a reliable Humidity Cabinet (MT-190 Series)? Micro Technologies manufactures and supplies premium humidity cabinets designed for pharmaceutical industries, biotechnology laboratories, agricultural research centres, universities, seed testing laboratories, food testing laboratories, hospitals, research institutes, and industrial quality control facilities. Contact us today for customized specifications, OEM manufacturing, government tenders, distributor inquiries, bulk orders, or a competitive quotation.
