Bidirectional Buffer Trainer Using 74245 IC
Product Specification Sheet
Bidirectional Buffer Trainer Using 74245 IC
Model Number: MT-E173
The Bidirectional Buffer Trainer Using 74245 IC is a professional laboratory training system designed for studying bidirectional data transfer and bus interfacing using the IC 74245 octal bus transceiver. Manufactured by Micro Technologies, this trainer incorporates logic input switches, output indicators, and practical digital buffer experiments, making it ideal for engineering colleges, universities, polytechnic institutes, technical training centers, and digital electronics laboratories.
Product Specification
The Bidirectional Buffer Trainer Using 74245 IC is specially designed to provide students with practical knowledge of bidirectional digital data transfer through hands-on laboratory experimentation. Manufactured by Micro Technologies, this trainer enables learners to understand the operation of bidirectional buffers, tri-state logic, bus interfacing, and data communication techniques used in modern digital systems, microprocessors, embedded systems, and computer architecture.
The trainer allows students to study the working principle of the 74245 Octal Bus Transceiver, enabling practical verification of bidirectional data transmission between two digital buses. Through experimentation, learners can understand data direction control, bus isolation, tri-state outputs, signal buffering, and digital bus communication.
The trainer incorporates an onboard IC 74245 Octal Bidirectional Bus Transceiver together with supporting combinational circuitry. Students can observe how digital information is transferred from one bus to another while controlling the direction of data flow through dedicated control signals.
Ten independent TTL logic input switches allow users to apply HIGH and LOW logic levels to the experimental circuit. Each logic input is accompanied by an LED indicator for easy visualization of logic status. Ten independent buffered logic output indicators display the transferred digital signals, enabling students to observe data flow and verify correct bidirectional operation.
The trainer operates from a regulated +5 V DC, 150 mA power supply, ensuring reliable operation of the onboard digital integrated circuits. Carefully selected electronic components provide stable performance, accurate signal transmission, and long operational life.
The front panel is manufactured using a premium insulated printed circuit board with permanently printed circuit diagrams and symbols for easy identification of experimental terminals and signal paths. Color-coded 2 mm safety sockets simplify laboratory wiring while minimizing connection errors.
The trainer is enclosed inside a rugged ABS plastic cabinet designed for continuous educational use. Compact tabletop construction makes it ideal for classroom demonstrations, laboratory practical sessions, and digital electronics training programs.
The Bidirectional Buffer Trainer Using 74245 IC is extensively used in engineering colleges, universities, diploma institutes, polytechnic colleges, industrial training institutes (ITI), vocational education centers, digital electronics laboratories, computer architecture laboratories, microprocessor laboratories, embedded systems laboratories, and research institutions.
Every Bidirectional Buffer Trainer manufactured by Micro Technologies undergoes comprehensive quality inspection and functional testing to ensure operational reliability, safety, and long service life.
Features
- Study of bidirectional buffer operation
- Built-in IC 74245 Octal Bus Transceiver
- Bidirectional data transfer experiments
- Bus interfacing demonstration
- Tri-state logic operation
- Ten independent TTL logic inputs
- LED logic input indicators
- Ten buffered logic output indicators
- Data direction control
- Regulated +5 V DC power supply
- High-quality insulated PCB
- Clearly printed circuit diagrams
- Color-coded 2 mm safety sockets
- Rugged ABS plastic cabinet
- Compact tabletop design
- Ready-to-use laboratory trainer
- Reliable experimental performance
- Low maintenance
- Instruction manual included
Benefits
- Demonstrates bidirectional bus communication clearly
- Enhances understanding of digital buffering techniques
- Supports digital electronics laboratory education
- Simplifies bus interfacing experiments
- Easy laboratory setup
- Safe low-voltage operation
- Improves knowledge of data transfer techniques
- Provides real-time logic indication
- Durable educational equipment
- Suitable for repeated classroom demonstrations
- Cost-effective engineering trainer
- Strengthens practical digital electronics skills
Product Specifications
| Specification | Details |
|---|---|
| Product Name | Bidirectional Buffer Trainer Using 74245 IC |
| Main IC | IC 74245 Octal Bus Transceiver |
| Experiment | Bidirectional Buffer & Bus Interfacing |
| DC Power Supply | +5 V DC, 150 mA |
| Input Supply | 230 V AC ±10%, 50 Hz |
| Logic Inputs | Ten Independent TTL Logic Inputs |
| Input Indicators | LED Logic Status Indicators |
| Logic Indicators | Ten Buffered Logic Output Indicators |
| Connection Type | 2 mm Color-Coded Safety Sockets |
| Circuit Board | High-Quality Insulated PCB |
| Cabinet | Heavy-Duty ABS Plastic |
| Trainer Size | Approximately 12" × 8" |
Applications
- Engineering Colleges
- Polytechnic Institutes
- Universities
- Digital Electronics Laboratories
- Microprocessor Laboratories
- Embedded Systems Laboratories
- Computer Architecture Laboratories
- Electronics Laboratories
- Diploma Colleges
- Industrial Training Institutes (ITI)
- Technical Training Centers
- Research Laboratories
Optional Accessories
- Digital Multimeter
- Logic Probe
- Logic Pulser
- Oscilloscope
- Function Generator
- Patch Cords (2 mm)
- Breadboard Trainer Kit
- Electronics Tool Kit
- Laboratory Workstation
- User Instruction Manual
SKU System
MT-BBT74245-001
FAQs
What is the Bidirectional Buffer Trainer Using 74245 IC used for?
It is used to study bidirectional data transfer, bus interfacing, tri-state logic, and digital buffering using the IC 74245 bus transceiver.
Which IC is provided on the trainer?
The trainer incorporates the IC 74245 Octal Bidirectional Bus Transceiver.
Which experiments can be performed?
Students can study:
- Bidirectional Data Transfer
- Bus Interfacing
- Tri-State Logic
- Direction Control
- Data Buffering
- Digital Bus Communication
How many logic inputs are available?
The trainer provides 10 independent TTL logic input switches, each with LED indication.
How many output indicators are available?
The trainer includes 10 buffered logic output indicators for monitoring transferred digital data.
What power supply is included?
The trainer operates on a regulated +5 V DC, 150 mA power supply.
How are experimental connections made?
All experimental connections are made through 2 mm color-coded safety sockets, ensuring secure and reliable laboratory operation.
Can the Bidirectional Buffer Trainer Using 74245 IC be supplied in bulk?
Yes. Micro Technologies supplies Bidirectional Buffer Trainers for engineering colleges, universities, government institutions, OEM projects, distributors, laboratory installations, and bulk procurement.
